SH-508i Veterinary Single Channel Syringe Infusion Pump
The SH-508i veterinary syringe pump offers precise fluid delivery for animal care. Featuring a single channel, large color LCD display, real-time alarm system, and electric medical infusion technology, it ensures accurate, safe, and reliable performance in veterinary clinics and hospitals.
SINOHERO SH-508i Veterinary / Human Syringe Pump – Single Channel Infusion Pump with Large Color Display
The SINOHERO SH-508i (SP950) Syringe Pump is a professional-grade electric medical infusion pump designed for both human and veterinary clinical use. Featuring a 2.8-inch color LCD, real‑time parameter display, and multi‑function alarms (occlusion, syringe fall‑off, low battery, etc.), this pump delivers high accuracy (±3%) and reliable performance. Compatible with 10ml, 20ml, 30ml, and 50ml disposable syringes, it supports flow rates up to 500ml/h and includes a built‑in rechargeable battery for uninterrupted operation. Ideal for ICU, CCU, neonatology, operating rooms, emergency, and veterinary clinics.
- 2.8-inch LCD color screen – clear real‑time data and alarm prompts
- Four syringe modes: 10ml / 20ml / 30ml / 50ml (CNS standard)
- Flow rate range: 0.1ml/h to 500ml/h (depending on syringe size)
- Three‑level occlusion alarm sensitivity (Low/Middle/High)
- Built‑in lithium battery (3500mAh) – 2+ hours of continuous operation
Key Features
- High‑Accuracy Microcomputer Control: Adopts advanced microcomputer and microelectronic technology. Infusion accuracy reaches ±3% to ensure precise drug delivery. Automatic syringe detection and calibration for 10ml/20ml/30ml/50ml syringes (CNS).
- Versatile Infusion Modes: Supports flow rate mode, time/volume mode, and drug/weight mode. Quick feed function (bolus) allows instant high‑speed delivery – 100ml/h for 10ml syringe, up to 500ml/h for 50ml syringe.
- Comprehensive Alarm System: Visual, audible, and character prompts for occlusion (3 adjustable pressure levels), syringe fall‑off, near empty, empty (KVO mode), motor failure, low battery, and communication error. Ensures patient safety at all times.
- KVO (Keep Vein Open) Mode: After infusion completes, automatically switches to KVO rate (0.1‑5ml/h, adjustable) to prevent venous occlusion and maintain line patency until the next intervention.
- Built‑in Rechargeable Battery: High‑capacity 3500mAh lithium battery provides at least 2 hours of continuous operation at 5ml/h or 500ml/h. Auto‑switch to battery power in case of AC failure – perfect for transport or power outages.
Compatibility and Best Use
- Human Medical Settings: Ideal for ICU, CCU, neonatology, obstetrics/gynecology, pediatrics, internal medicine, surgery, operating rooms, and emergency departments. Suitable for precise intravenous infusion of medications, anesthetics, or nutrients.
- Veterinary Clinics: Specifically designed for veterinary use (SH‑508i VET model). Works with standard 10‑50ml syringes for animal patients – dogs, cats, horses, and other large/small animals requiring controlled infusion.
- Power and Environment: Operates on AC100‑240V, 50/60Hz – worldwide voltage compatibility. Working temperature: +5 to 40°C, relative humidity 20‑90%. No strong vibration or corrosive gas.
- Safety Classification: Class II equipment, internally powered type BF (body floating) – safe for direct cardiac contact when used with proper accessories.
- Storage & Transport: Storage temperature -20 to +55°C, humidity ≤90% (no condensation). Well‑ventilated, corrosive‑gas‑free environment recommended.
Installation Tips
- Syringe Loading: Use only disposable syringes (CNS standard) of 10ml, 20ml, 30ml, or 50ml. Follow on‑screen prompts to secure syringe correctly. The pump automatically detects syringe size and adjusts flow limits.
- Setting Up Infusion Parameters: Turn on device, select infusion mode (flow rate, time/volume, or drug/weight). Enter desired rate, volume, or drug dose. Confirm settings before starting infusion.
- Alarm Pressure Adjustment: Set occlusion alarm sensitivity (Low ≈40KPa, Middle ≈70KPa, High ≈100KPa) based on patient needs and fluid viscosity. Lower pressure for neonates/ small animals, higher for viscous fluids.
- Quick Feed (Bolus) Use: Press the quick feed button to deliver a high‑speed bolus (e.g., 500ml/h for 50ml syringe). Use only when immediate drug administration is clinically required – do not exceed recommended bolus volume.
- Battery Charging: Keep the pump plugged into AC power when not in use to maintain battery charge. A fully charged battery supports at least 2 hours of operation at any rate up to 500ml/h. The device auto‑charges and auto‑switches to battery backup.
Product Specifications
| Brand Name | SINOHERO (Model SP950 / SH-508i) |
| Intended Use | Human / Veterinary Infusion Pump |
| Display | 2.8″ LCD LED Color Screen |
| Syringe Compatibility | 10ml / 20ml / 30ml / 50ml (CNS disposable syringes) |
| Infusion Rate Range | 10ml: 0.1‑100ml/h; 20ml: 0.1‑200ml/h; 30ml: 0.1‑300ml/h; 50ml: 0.1‑500ml/h |
| Quick Feed Rate (Bolus) | 10ml: 100ml/h; 20ml: 200ml/h; 30ml: 300ml/h; 50ml: 500ml/h |
| Infusion Accuracy | ±3% |
| Accumulated Volume Display | 0.0 ‑ 999.9 ml |
| Occlusion Alarm Pressure Levels | Low: 40±16KPa; Middle: 70±30KPa; High: 100±35KPa (3‑level adjustable) |
| KVO Rate | 0.1 ‑ 5.0 ml/h (adjustable) |
| Alarm Functions | Non‑operated, near empty, empty (KVO), syringe fall‑off, occlusion, pressure failure, motor failure, low battery, communication abnormal |
| Max Power Consumption | 20VA ‑ 30VA |
| Power Supply | AC 100‑240V, 50/60Hz (worldwide) |
| Battery | Rechargeable lithium battery, 7.4V, 3500mAh (runtime ≥2 hours at 5ml/h or 500ml/h) |
| Safety Classification | Class II equipment, internally powered type BF |
| Working Environment | Temp: +5 to 40°C; Humidity: 20‑90%; Pressure: 860‑1060hPa; No strong vibration / corrosive gas |
| Storage Environment | Temp: -20 to +55°C; Humidity ≤90% (no condensation); Well‑ventilated |
| Material | ABS Plastic |
| Certification | 3C Certified, no high‑concerned chemicals |
| Origin | Mainland China |
Packing List
– 1 x SINOHERO SH-508i / SP950 Syringe Pump (single channel)
– 1 x AC power cord (US standard plug, compatible 100‑240V)
– 1 x Built‑in rechargeable lithium battery (already installed)
– 1 x User manual / operation guide
– 1 x Syringe holder adapter set (for 10/20/30/50ml syringes)
– 1 x Quick reference card for alarm codes
– 1 x AC power cord (US standard plug, compatible 100‑240V)
– 1 x Built‑in rechargeable lithium battery (already installed)
– 1 x User manual / operation guide
– 1 x Syringe holder adapter set (for 10/20/30/50ml syringes)
– 1 x Quick reference card for alarm codes
Warnings and Safety Notes
For prescription use only – this device must be operated by trained medical or veterinary professionals. Do not use without proper training.
Always verify syringe brand and size compatibility before use. Incompatible syringes may cause inaccurate flow or occlusion.
Do not modify or disassemble the pump. Service only by authorized personnel to maintain safety and accuracy.
Keep the pump away from strong electromagnetic interference (MRI, diathermy equipment) to prevent malfunction.
Do not immerse in liquids. Clean exterior with a soft, damp cloth. Avoid alcohol or abrasive cleaners that may damage the screen.
The BF‑type patient connection is safe for cardiac application, but always use appropriate sterile disposables and follow infection control protocols.
If the occlusion alarm activates, check the IV line and syringe for kinks or clots before resetting. Do not bypass alarm settings.
Battery must be recycled properly. Do not short circuit, incinerate, or expose to high temperatures.
Regularly inspect power cord and plug for damage. Do not use if cord is frayed or exposed wires are visible.
Store in a clean, dry environment when not in use. Avoid direct sunlight and extreme temperatures.
Always verify syringe brand and size compatibility before use. Incompatible syringes may cause inaccurate flow or occlusion.
Do not modify or disassemble the pump. Service only by authorized personnel to maintain safety and accuracy.
Keep the pump away from strong electromagnetic interference (MRI, diathermy equipment) to prevent malfunction.
Do not immerse in liquids. Clean exterior with a soft, damp cloth. Avoid alcohol or abrasive cleaners that may damage the screen.
The BF‑type patient connection is safe for cardiac application, but always use appropriate sterile disposables and follow infection control protocols.
If the occlusion alarm activates, check the IV line and syringe for kinks or clots before resetting. Do not bypass alarm settings.
Battery must be recycled properly. Do not short circuit, incinerate, or expose to high temperatures.
Regularly inspect power cord and plug for damage. Do not use if cord is frayed or exposed wires are visible.
Store in a clean, dry environment when not in use. Avoid direct sunlight and extreme temperatures.
